CNE-S03-GY - Sensor Connectors
Sensor Connector
- SKU:
- CNE-S03-GY
- Category:
- Proximity Sensors
- Brand:
$13.98
Share product:
100% Guarantee Safe Checkout
Shipping calculated at the checkout
Specifications
- AWG
- AWG20-22
- Material
- Body: PBS (UL94V-0), Terminal: C510 (gold 0.2m),Case: PC (UL94-V0)
- Insertion
- Max. 1.96N (200gfin
- Extraction
- Min. 0.49N (50fin
- Cover color
- Gray
- Power voltage
- ?32VACDC(=)
- Rated current
- Max. 3.0A
- Cover diameter
- 1.6 to 2.0mm
- Number of pins
- 3-pin
- Terminal retention
- Min. 1.4kgf
- Nominal cross Section Area
- 0.32~0.5mm sq
Description
The CNE-S03-GY is an M12 3-pin male field-wireable sensor connector in gray. As the male counterpart to CLD-type female cables, it allows custom cable routing and field termination without pre-manufactured cable assemblies. Suitable for retrofit installations and applications requiring non-standard cable routing geometries.
