CNE-P03-BL - Sensor Connectors
Sensor Connector
- SKU:
- CNE-P03-BL
- Category:
- Proximity Sensors
- Brand:
$13.98
Share product:
100% Guarantee Safe Checkout
Shipping calculated at the checkout
Specifications
- AWG
- AWG20-22
- Material
- Body: PBS (UL94V-0), Terminal: C510 (gold 0.2m),Case: PC (UL94-V0)
- Insertion
- Max. 1.96N (200gfin
- Extraction
- Min. 0.49N (50fin
- Cover color
- Blue
- Power voltage
- ?32VACDC(=)
- Rated current
- Max. 3.0A
- Cover diameter
- 1.2 to 1.6mm
- Number of pins
- 3-pin
- Terminal retention
- Min. 1.4kgf
- Nominal cross Section Area
- 0.32~0.5mm sq
Description
The CNE-P03-BL is an M12 3-pin female field-wireable sensor connector in blue color, allowing custom-length cable assembly on-site. The color-coded blue housing enables quick visual identification of specific sensor circuits in multi-connector panel wiring. Suitable for use with 3-wire NPN or PNP sensor outputs where standardized cable lengths are not applicable.
