AS80-50DN3 - Rectangular Inductive Long-Distance Proximity Sensors
Inductive Proximity Sensor
- SKU:
- AS80-50DN3
- Category:
- Proximity Sensors
- Brand:
$156.88
Share product:
100% Guarantee Safe Checkout
Shipping calculated at the checkout
Specifications
- Weight
- Approx. 470
- Sensing type
- Upper sensing type
- Control output
- NPN Normally Open+Normally Closed
- Sensing distance
- 50m
- Sensing side size
- Frame size 80mm
- Response frequency
- 30Hz
- Wire type and power
- DC 4-wire type12-48VDC (=)
- Hysteresis(distance)
- Max. 15% of sensing distance
- Protection structure
- IP67(IEC standard)
- Current specification
- Current consumption: Max. 20mA
- Standard sensing target
- 1501501mm(iron)
- Environment_Ambient humidity
- 35 to 95% RH, storage: 35 to 95% RH
- Environment_Ambient temperature
- -25 to 70storage30 to 80
Description
The AS80-50DN3 is a rectangular inductive long-distance proximity sensor with an 80 mm body and a sensing distance of 50 mm. It features an NPN normally-open output configuration and operates on a DC supply. The extended sensing range makes it well-suited for detecting large metallic targets or for applications where mounting close to the target is not feasible, such as in heavy machinery, press equipment, and material handling systems.
