ABL-L01PA-NN - Relay Terminal Blocks (Screwless Push-In Type)
Relay Terminal Block
- SKU:
- ABL-L01PA-NN
- Category:
- Proximity Sensors
- Brand:
$18.46
Share product:
100% Guarantee Safe Checkout
Shipping calculated at the checkout
Specifications
- Weight
- Approx. 138g(approx. 21g)
- Material
- Terminal block: Polyamide 66, Conducting plate: Brass,Case&BASE: Poly phenylene sulfide
- Indicator
- Operation indicator: Blue LED
- Applied relay
- APAN3124 [MATSUSHITA(Panasonic)]
- Rated voltage
- 24VDC (=) 10%
- Terminal type
- Screwless
- Terminal pitch
- 9.0mm(arranging over 2 units)
- Current consumption
- 8mA
- Protection structure
- IP20(IEC standard)
- Insulation resistance
- 1,000 M (50 VDC(=) megger)
- Number of relay points
- 1-point
- Applicable cable_Solid wire
- 0.6 t1.25mm(60only)
- Environment_Ambient humidity
- 35 to 85% RH, storage: 35 to 85% RH
- Rated load voltage & current
- 250AC50z 3A,30VDC (=) 3A
- Applicable cable_Stranded wire
- AWG22-16(0.1.25mm sq)(60only)
- Environment_Ambient temperature
- -15 to 55, storage: -25 to 65
- Dielectric strength_Between coil-contacts
- 3,000VA50z for 1 minute
- Dielectric strength_Between same contacts
- 1,000VA50z for 1 minute
Description
The ABL-L01PA-NN is a screwless push-in type relay terminal block designed for fast, tool-free conductor insertion. It accommodates solid, stranded, and ferrule-terminated wires, providing secure electrical connections in DIN rail-mounted control panel assemblies. Rated for industrial environments, this terminal block offers reduced wiring time, vibration-resistant contact retention, and compact footprint suitable for high-density wiring applications.
