Nitto Hi Cupla Socket - 1/4" Hose Barb, Steel (Barb Lock), Quick Connect Coupling, MODEL NAME: 20SH-BL
Carbon Steel body | NBR (Buna-N) seal | 1/4" socket, Barb Lock Design
- SKU:
- 313102361
- Category:
- Steel Coupling
- Brand:
$15.68
Share product:
100% Guarantee Safe Checkout
Shipping calculated at the checkout
Specifications
- SIZE
- 1/4"
- SERIES
- HI CUPLA
- MODEL NAME
- 20SH-BL
- BODY MATERIAL
- STEEL
- SEAL MATERIAL
- NBR
- CONNECTION TYPE
- SOCKET
- END CONFIGURATION
- HOSE
Description
Nitto Kohki Hi Cupla series quick-disconnect socket with a carbon steel body and 1/4" hose barb connection. Part number 313102361. The socket uses NBR (Buna-N) seals for fluid compatibility. Features a barb lock (BL) design that secures the hose barb connection against accidental pull-out. Designed for push-to-connect/one-touch operation, compatible with Hi Cupla series mating components.
